Steel Manufacturer Machines
Strong. Reliable. Built by HPT.
HPT, A Leading Manufacturer of Steel Manufacturer Machines
Hydro Power-Tech Engineering (HPT), based in Gujarat, India, has built a strong reputation for delivering high-performance Hydraulic Steel Manufacturer Machines.
Structural steel machinery plays a vital role in precision fabrication, enabling efficient cutting, bending, welding, and assembling of steel components for construction and industrial projects. High-quality machinery ensures speed, accuracy, and safety throughout the fabrication process.
- Ensures speed, accuracy, and safety in steel fabrication.
- Streamlines operations while reducing manual labor.
At United Structural Works, we deliver advanced structural steel machinery designed to boost efficiency and reliability. Our robust and user-friendly equipment streamlines operations, reduces manual labor, and ensures superior-quality steel components for modern construction needs.
“Power. Precision. Performance – The HPT Ironworker Promise.”
Ironworker Machine Features
Precision Cutting:
Advanced CNC cutting systems ensure clean, accurate cuts for beams, plates, and angles, reducing material wastage.
Bending and Shaping:
High-performance bending machines capable of producing precise shapes for complex structural designs.
Efficient Drilling and Punching:
Automated systems for efficient hole-making, essential for structural assembly and welding tasks.
Integrated Marking:
Accurate marking systems for quick identification of drill points, welds, and other key specifications.
Safety and Manufacturing Considerations
Safety is a top priority when it comes to operating structural steel machinery. At United Structural Works, we prioritize the integration of safety features into all our machines. From emergency stop systems to advanced safety shields, every unit is designed to ensure a secure working environment.
Our rigorous quality control processes ensure that every machine meets industry standards for performance and safety. By choosing machinery from United Structural Works, you’re ensuring that your fabrication shop operates smoothly with minimal downtime and maximum output.
Steel Machinary - Benefits of Using Structural Steel Machinery
Increased Efficiency: Automation reduces manual intervention, allowing for faster project completion.
High Precision: Our machines are engineered to meet strict tolerances, ensuring every component fits perfectly, even in large-scale projects.
Reduced Labor Costs: With advanced machinery handling most tasks, fewer workers are required for complex jobs, improving your bottom line.
Durability and Reliability: Built to withstand the demands of heavy-duty projects, our machines are made with high-quality materials for long-term use.
Technical Specifications - HIW Series
Punching Specifications
| Particular | HIW – 55 | HIW – 65 | HIW – 85 | HIW – 110 | HIW – 110 EX | HIW – 135 | HIW – 165 | HIW – 220 |
|---|---|---|---|---|---|---|---|---|
| Punching Pressure | 55 Ton | 65 Ton | 85 Ton | 110 Ton | 110 Ton | 135 Ton | 165 Ton | 220 Ton |
| Punch Capacity (Dia x Thickness) | 22 x 16 45 x 8 |
22 x 20 50 x 9 |
30 x 20 50 x 12 |
30 x 25 50 x 15 |
30 x 25 50 x 15 |
33 x 28 50 x 18 |
36 x 32 50 x 23 |
40 x 38 50 x 30 |
| Throat Depth (S / SD Model) | 275 / – | 310 / 510 | 310 / 510 | 310 / 510 | 310 / 510 | 570 / – | 570 / – | 570 / – |
| Maximum Stock Length | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Cycle/Min. (20mm Stroke) | 25 / 32 | 20 | 21 | 21 | 21 | 20 | 25 | 25 |
| Working Height up to Die | 910 | 910 | 950 | 950 | 950 | 1020 | 1050 | 1050 |
Flat Shearing Capacity
| Perticular | HIW – 55 | HIW – 65 | HIW – 85 | HIW – 110 | HIW – 110 EX | HIW – 135 | HIW – 165 | HIW – 220 |
|---|---|---|---|---|---|---|---|---|
| Flate Bar Shear (Width x Thickness) | 300 x 12 240 x 16 |
350 x 15 240 x 20 |
460 x 15 300 x 20 |
610 x 16 400 x 20 |
610 x 16 400 x 20 |
610 x 18 400 x 25 |
760 x 20 400 x 30 |
700 x 25 425 x 30 |
| Blade Length | 310 | 360 | 465 | 620 | 620 | 620 | 770 | 720 |
| Angle Flange Trim | 65 | 75 | 100 | 100 | 100 | 100 | 120 | 120 |
| Working Height | 820 | 920 | 920 | 950 | 950 | 950 | 950 | 950 |
Angle Shearing Details
| Perticular | HIW – 55 | HIW – 65 | HIW – 85 | HIW – 110 | HIW – 110 EX | HIW – 135 | HIW – 165 | HIW – 220 |
|---|---|---|---|---|---|---|---|---|
| Angle 90 Shearing | 100 x 100 x 10 | 130 x 130 x 13 | 152 x 152 x 13 | 152 x 152 x 15 | 152 x 152 x 15 | 152 x 152 x 18 | 200 x 200 x 20 | 200 x 200 x 20 |
| Angle 45 Miter Shearing | 50 x 50 x 6 | 65 x 65 x 8 | 80 x 80 x 10 | 80 x 80 x 10 | 80 x 80 x 10 | 80 x 80 x 10 | 80 x 80 x 10 | 100 x 100 x 10 |
| Working Height | 1080 | 1150 | 1150 | 1150 | 1150 | 1160 | 1160 | 1160 |
Section & Bar Shearing
| Perticular | HIW – 55 | HIW – 65 | HIW – 85 | HIW – 110 | HIW – 110 EX | HIW – 135 | HIW – 165 | HIW – 220 |
|---|---|---|---|---|---|---|---|---|
| Round Bar Shearing | 32 | 40 | 50 | 50 | 50 | 50 | 60 | 70 |
| Square Bar Shearing | 32 x 32 | 38 x 38 | 50 x 50 | 50 x 50 | 50 x 50 | 50 x 50 | 60 x 60 | 60 x 60 |
| Channel Shearing | 125 | 152* | 180* | 180* | 200* | 200* | 250* | 300* |
| I Beam Shearing | 125 | 152* | 180* | 180* | 180* | 180* | 200* | 300* |
| Working Height | 1150 | 1300 | 1300 | 1315 | 1315 | 1315 | 1375 | 1375 |
Notching Specifications
| Perticular | HIW – 55 | HIW – 65 | HIW – 85 | HIW – 110 | HIW – 110 EX | HIW – 135 | HIW – 165 | HIW – 220 |
|---|---|---|---|---|---|---|---|---|
| Rectangular (W x D x T) | 50.8 x 90 x 6 | 50.8 x 90 x 9 | 50.8 x 90 x 12 | 63.5 x 90 x 12 | 63.5 x 90 x 12 | 63.5 x 90 x 13 | 63.5 x 90 x 16 | 63.5 x 90 x 18 |
| Vee-Notcher (Side x Side x T) | 80 x 80 x 6 | 90 x 90 x 8* | 90 x 90 x 10* | 105 x 105 x 12* | 105 x 105 x 12* | 105 x 105 x 13* | 105 x 105 x 16* | 105 x 105 x 16* |
| Large V-Notcher (Side x Side x T) | – | 145 x 145 x 8 | 145 x 145 x 10 | 145 x 145 x 12 | 145 x 145 x 12 | 145 x 145 x 13 | 145 x 145 x 13 | 145 x 145 x 15* |
| Working Height | 850 | 850 | 860 | 860 | 860 | 860 | 920 | 920 |
Optional Tooling
| Perticular | HIW – 55 | HIW – 65 | HIW – 85 | HIW – 110 | HIW – 110 EX | HIW – 135 | HIW – 165 | HIW – 220 |
|---|---|---|---|---|---|---|---|---|
| Single V Press Break (W x T) | 250 x 10 | 250 x 15 | 250 x 15 | 250 x 20 | 250 x 20 | 250 x 20 | 250 x 20 | 250 x 20 |
| Multi V Press Break (W x T) | 400 x 5 | 500 x 5 | 500 x 5 | 700 x 5 | 700 x 5 | 700 x 5 | 700 x 6 | 700 x 6 |
| Angle Bending | 76 x 6 | 102 x 6 | 102 x 8 | 102 x 13 | 102 x 13 | 102 x 13 | 102 x 13 | 102 x 13 |
| Pipe Notcher (Dia.) | 114 | 114 | 114 | 114 | 114 | 114 | 114 | 114 |
Other Specifications
| Perticular | HIW – 55 | HIW – 65 | HIW – 85 | HIW – 110 | HIW – 110 EX | HIW – 135 | HIW – 165 | HIW – 220 |
|---|---|---|---|---|---|---|---|---|
| Electric Power (HP) | 7.5 HP | 7.5 HP | 10 HP | 10 HP | 10 HP | 15 HP | 20 HP | 25 HP |
| Net Weight (Apr.) S / SD | 2300 / 2300 KG | 2600 / 3100 KG | 2950 / 3250 KG | 3600 / 3900 KG | 3950 / 4200 KG | 5200 KG | 6500 KG | 7800 KG |
| Machine Dimensions (L x W x H) | 1750 x 750 x 1800 | 1970 x 800 x 2000 | 2100 x 820 x 2060 | 2340 x 860 x 2110 | 2400 x 920 x 2150 | 2420 x 980 x 2150 | 2550 x 1050 x 2150 | 2700 x 1200 x 2250 |
Elevate Your Steel Fabrication with United - Structural Works
When it comes to structural steelwork, investing in the best machinery is crucial for achieving precision, safety, and efficiency in your operations. United Structural Works offers a comprehensive range of structural steel machinery designed for both small workshops and large-scale industrial projects.
Whether you’re cutting, bending, or drilling, our advanced machinery streamlines your processes, helping you meet deadlines and exceed quality expectations. Ready to enhance your fabrication capabilities? Choose United Structural Works for top-tier structural steel machinery that gets the job done.
Built for Precision and Performance
Watch Our Hydraulic Steel Machines in Action :
Discover the power, precision, and versatility of our Hydraulic Ironworker Machines through our live demonstration video. Watch how our HIW-55 to HIW-220 models handle punching, shearing, and bending operations seamlessly.
